Description
A 5.12 kWh LiFePO4 (Lithium Iron Phosphate) battery is often used in energy storage systems, including solar power setups, backup power systems, and off-grid solutions. Here’s an overview of the specifications and features typically associated with such a battery:
Key Specifications:
- Battery Type: Lithium Iron Phosphate (LiFePO4)
- Capacity: 5.12 kWh (kilowatt-hours)
- Voltage: Usually 48V (but can vary; some might be 24V systems)
- Charge/Discharge Cycles: Often rated for 3000-6000 cycles at 80% Depth of Discharge (DoD)
- Rated Capacity: Around 100-200 Ah (Amp-hours), depending on the specific model
- Efficiency: High round-trip efficiency, usually between 95-98%
- Operating Temperature Range: Commonly -20°C to 60°C for discharge, 0°C to 45°C for charging
- Weight: Approximately 40-60 kg (depending on the specific configuration and casing)
- Dimensions: Varies, but typically compact for easier installation (e.g., wall-mountable or rack-compatible)
Features:
- Safety: LiFePO4 chemistry is known for being stable and safe, with lower risks of overheating or thermal runaway compared to other lithium-ion chemistries.
- Longevity: These batteries have a long cycle life, making them ideal for renewable energy applications where frequent cycling is required.
- BMS (Battery Management System): Includes protection for over-voltage, over-current, short-circuit, and temperature monitoring to extend battery life and enhance safety.
- Scalability: Can be connected in series or parallel to increase voltage or capacity, allowing for expansion as energy needs grow.
Specifications:
|
Electrical Characteristics
|
 Nominal Voltage |  51.2V |
|  Nominal Capacity |  100Ah (C5,25°C) | |
| Â Energy | Â 5120Wh | |
|  Internal Resistance |  <50mΩ | |
|  Cycle Life |  >10000 cycles @25°C | |
| Â Months Self Discharge | Â <3% | |
| Â Efficiency of Charge | Â 100% @0.2C | |
| Â Efficiency of Discharge | Â 96~99% @1C | |
|
Standard Charge
|
 Charge Voltage |  58.4V |
|  Charge Mode |  0.2C to 58.4V, then 58.4V charge current  0.02C(CC/CV) | |
| Â Charger Current | Â 20A | |
| Â Max. Charge Current | Â 50A | |
| Â Charge Cut-off Voltage | Â <59.2V | |
|
Standard Discharge
|
 Continuous Current |  50A |
| Â Max. Pulse Current | Â 110A(<3s) | |
| Â Discharge Cut-off Voltage | Â 44V | |
|
Environmental
|
 Charge Temperature |  0°C to 45°C (32F to 113F) @60±25% Relative Humidity |
|  Discharge Temperature |  -20°C to 60°C (-4F to 140F) @60±25% Relative Humidity | |
|  Storage Temperature |  0°C to 40°C (32F to 104F) @60±25%  Relative  Humidity | |
| Â Water Dust Resistance | ||
|
Mechanical
|
 Cell & Method |  3.2V50AH-16S2P |
| Â Plastic Case | ||
|  Dimensions (in./mm.) |  600*420*210±2mm | |
| Â Weight (lbs./kg.) | Â 53Kg | |
| Â Terminal | Â 180A terminal | |
| Â Protocol (optional) | Â RS485/CAN | |
| Â BMS | Â 16S100A |
