NovaStar H9 Enhanced H Series Video Wall Splicer

Description

Configured to Your Specific Application

Each H9 Enhanced Unit Includes:

• Front panel with screen
• One power supply
• Control card
• Power switch
• Genlock In/Loop
• Ethernet port for network control
• USB port for software control
• RS232 ports for communication

H9 Specifications:

• Supports up to 15 input cards and up to 5 output cards
• Loading capacity: 65,000,000 pixels
• Maximum input channels: 60
• Maximum number of screens: 20

Available Input Cards:

• 4x DVI card
• 4x HDMI card (2x HDMI 1.3 + 2x HDMI 1.4a)
• 1x HDMI 2.0 + 1x DP 1.2 card (only one connector can be used at a time)
• 1x HDMI 2.0 card
• 2x RJ45 Gigabit Ethernet card + 1x USB input
• 4x 3G-SDI card
• 1x 12G SDI IN + 1x 12G SDI Loop
• Analog (VGA) card
• 2x DP1.1 card
• 1x HDMI 2.0
• 2x HDMI 2.0
